Chamberlain LM950 Automatic Roller Garage Door Opener

This new garage door opener from Liftmaster exclusively suits residential roller curtain garage doors. The motor unit is mounted directly to the existing roll shaft and a forked device engages with the spoked wheel within the roll to provide the motion.

Specification LM950EVGB
Input voltage 220 - 240Vac, 50 - 60 Hz
Motor voltage 12VDC
Transformer rating 80VA
Drive system Direct drive
Standby power < 1 Watt
Pulling force @ 300mm dia drum 1300N
Watts 110 Watts
Rated load ( Torque ) 25Nm
Overload protection Yes
Temperature range Minus 25 / plus 55 Celsius
Installation orientation Left or right hand side (limits)
Extension poles for deep reach Yes x 2
Rated door area 25m²
Max door height 5.5 meter
Max door weight 250kg
Min side room 45mm
Standard side room 95mm
Max door axle diameter 35mm
Travel speed ~23 seconds (2.3 high)
Number of drum rotations 4 1/2
Noise 59dBA
Radio 433.92MHz rolling code
Number of memory registrations 64
Radio signal range Up to 160 meters (free field)
Lighting 12 LEDs, ultra bright
Safety Auto reverse
Auto close ( IRs req'd ) Yes, 1 min, 5 min or 10 min
Soft start / stop Yes
Automatic limit & force setting Yes
Diagnostic LED system Yes
Warranty 2 years
Certification TUV
Accessory output No
Internal release device Yes
Water - resistant rating n/a
Maintenance counter no

Supplied with full instructions in English and a British 13amp 3-PIN plug.
