Description

Domino Keyless Entry System

Consisting of an outside permanently mounted keypad and inside control box. the DOMINO KEYLESS SYSTEM uses a 1 to 6 digit user code. making the system as easy to program as it is to install.

Features & Benefits

• Universal Use – Compatible with all garage door openers (connects to same terminals as the internal wall control pushbutton)
• Easy programming – System is quickly programmed in three simple steps.
• Tamper Proof – keypad shuts off for one minute after five wrong entries have been pressed.
• Cutting the cable to the inside control box or “shorting” the wires will not activate the opener.
• Weatherproof Flip-up Cover – Design protects the unit against the elements.
• Personalised User Code – A one to six digit code may be chosen to provide up to 1.000.000 possibilities.
• Back Lighting – Illuminated keypad for easy night-time operation. Additional indicator light provides verification as keys are pressed.
• Low Power Warning/Battery Saver – Lights dim to indicate batteries should be replaced soon.  Special sleep circuitry conserves battery life.
• Instant Stop – After code is entered and garage door opener is activated. the “enter” key may be pressed again to stop or reserve the door. without re-entering the code.  The “enter” key remains active for 20 seconds.
• Additional push button conveniently located on control box allows door operation from inside garage.

Technical Specifications

• Outside keypad size: Length 5″ (12.5cm): Width 2″ (5cm): Depth .6″ (1.5cm).
• Inside Control Box Size: Length 3″ (7.5cm): Width 4.5″ (11.5cm): Depth 1.4″ (3.5cm)
• Materials: ABS plastic; Elastomeric silicone keypad.
• Electrical Input: 3 AA Duracell alkaline batteries.
• Electrical Output: 1 amp dry contact relay giving a 0.3 – 3.5 second activation.
