Garage Door Operator – Novomatic 573 S belt drive

A domestic garage door operator, the Novomatic 573 S belt drive, designed for residential use in dry areas. The device features a compact 24 V DC gear-driven motor housed in a sleek, rectangular casing with integrated LED lighting. The operator is mounted on a single-part C-profile channel with a toothed belt, suitable for doors up to 18 m². Included are two 2-button mini Novotron 522 hand transmitters (433 MHz) with rolling code, and a quick-release mechanism for manual operation from inside the garage. The electronics control unit has a 7-segment display with diagnostic menus and an electrically monitored anti-opening security device. The system supports soft start/stop functionality and can lift doors up to 2250 mm rear-mounted or 2375 mm front-mounted. Ideal for home garages, it operates quietly and efficiently, backed by a 5-year warranty.

Operator details

• 24 V DC gear drive
• Mains voltage 230 – 240 V / 50Hz AC, 280 W
• Maximum pull/push force 800 N
• Maximum opening speed 24 cm/s
• Maximum closing speed 17 cm/s
• Soft start/stop

Electronics control unit:

• Electrically monitored anti-opening security device
• Standby power <0.5W
• 7-segment display menu guided control with diagnostic display
• Microprocessor

Operator boom – Belt

• 1 part C-profile channel with toothed belt
• Suits residential doors up to 18m square
• Doors – rear mount up to 2250mm high
• Doors – front mount up to 2375mm high

Standard equipment:

• Two 2-button mini Novotron 522 hand transmitters 433 MHz with Keeloq rolling code
• Quick release operated from the inside
• LED lighting
• Radio operated

5 Year Warranty
