Novoferm Novomatic 423 Garage Door Opener Beltdrive

Novomatic 423 Beltdrive Operator

Novoferm Novomatic 423 Garage Door Opener Beltdrive


Garage door opener specifications:

  • Max garage door size 10 m²
  • Max garage door weight 160 Kg
  • Boom length 3000 mm / movement range up to 2560 mm


  • Two handsets
  • Belt boom


SKU: NOO1010 Categories: , , ,
  • Description
  • Features
  • Additional Technical Information


Garage Door Operator – Novomatic 423 belt drive

Garage door automation has never been easier.  The Novomatic 423 opener is designed for up and over and sectional garage doors. The ultra-reliable, near silent belt drive operator incorporates a courtesy light and internal quick release.

Garage door operator for domestic use – not suitable for commercial use! For dry areas only.

Novomatic features at a glance:

  • 600N max push/pull force
  • Simple operation
  • Soft start and soft stop function
  • Integrated shutdown stopping device and electronically monitored push-up safeguard
  • Programmable inside lighting and connectable outside lighting
  • Two hand transmitters included as standard
  • Power economiser
  • Manual quick unlocking device in case of power cut etc.
  • Air vent settings for garage ventilation

Operator details

  • 24 V DC gear drive
  • Mains voltage 230 – 240 V / 50Hz AC, 280 W
  • Maximum pull/push force 600 N
  • Maximum running speed 15 cm/s
  • Soft start/stop

Electronic control unit:

  • Electrically monitored anti-opening security device
  • Standby power <0.5W
  • 7-segment display menu guided control with diagnostic display
  • Microprocessor

Operator boom - Belt

  • 1 part C-profile channel with toothed belt
  • Suits residential doors up to 10m square
  • Doors - rear mount up to 2250mm high
  • Doors - front mount up to 2375mm high

Standard equipment:

  • Two 2-button mini Novotron 522 hand transmitters 433 MHz with Keeloq rolling code
  • Quick release operated from the inside
  • Integral LED 1.6W garage lighting
  • Radio operated
