Hormann Supramatic P Bisecur Series 3 Head Only

supramatic

Hormann Supramatic P Bisecur Series 3 Head Only

£300.00

Available

  • Description

Description

Garage Door Operator – SupraMatic P BiSecur – Series 3 (Head Only)

One way photocell EL 101 as standard-High-speed opening

Product description:

Garage door operator for domestic use – not suitable for commercial use!

For dry areas only

No. of parking operations:

Max 50 door cycles (open/close) per day or 25 parking operations

Operator details:

  • 24 V DC gear drive
  • Mains voltage 230 – 240 V AC, 0.2 kW
  • Push and pull force 750 N, peak force 1.000 N
  • Opening speed 22 cm/s

Electronics control unit:

  • Microprocessor control
  • Automatic adjustment of safety cut-out and travel limits
  • Adjustable soft start and soft stop
  • 7-segment display
  • Operator light and second opening height adjustable
  • Automatic timer adjustable
  • Hold-open time 10 – 180 sec after activation
  • Impulse control

Operator boom FS 10 (at additional cost):

  • Self-supporting steel boom with polyester/polyamide toothed belt
  • Plastic slide carriage and automatic belt tensioner
  • 1-piece, completely pre-assembled

Operator boom FS 2 (at additional cost):

As boom FS 10 but 2 piece, pre-assembled

Standard equipment:

  • With 5-button HS 5 BS and 2-button HSE 2 BS hand transmitters
  • Operator lighting and second opening height
  • Each hand transmitter factory-coded individually from over 1 trillion combinations
  • Quick release operated from the inside connecting cable with CEE plug
  • Integral garage light with factory set 2-minute light
  • Radio operated
  • Door security kit as safety device
  • One-way photocell EL 101 as an additional safety device
  • Universal installation bracket for up-and-over doors and sectional doors

Housing:

Aluminium and plastic

Temperature range:

From – 20°C up to + 60°C

Note:

Installation of photocell is required if automatic timer is activated
