Hormann SupraMatic P Garage Door Opener BiSecur Series 4 Head Only

Hormann SupraMatic garage door opener

Hormann SupraMatic P Garage Door Opener BiSecur Series 4 Head Only

£395.00

Garage door opener specifications:

  • Max garage door width 6000 mm
  • Max garage door height depends on boom selected
  • Max garage door surface 15 m²

Included:

  • Two handsets

Available

  • Description
  • Additional Technical Information
  • Downloads

Description

Garage Door Operator – SupraMatic P BiSecur – NEW Series 4 (Head Only)

The latest generation of Hörmann garage door operators now feature the new Hörmann integrated Bluetooth receiver. The SupraMatic garage door operators feature the same proven Hörmann technology as all Hörmann premium operators.

Some of the NEW series 4 operator features include:

  • Energy-efficient LED lighting for bright, even garage illumination
  • Low power consumption of less than 1 watt in stand-by mode
  • Integrated Bluetooth receiver (can be turned on and off) for controlling the operator using the BlueSecur app on a smartphone
  • Up to 75% faster door opening in comparison to ProMatic series 3
  • New 3rd opening height for “Ventilation” setting
  • HCP interface to connect accessories or external SmartHome systems

SupraMatic P

  • Pull and push force: 750N
  • Peak force: 1000N
  • Opening speed: max. 25 cm/s ¹
  • Door width: up to 6000 mm (max. 15.00 m² door surface)

1) Depending on door type, door leaf weight and door size

Garage door operator for domestic use - not suitable for commercial use! For dry areas only.

Product Description:

Door cycles (Open / Close) Per day / per hour 50 / 10
Doors with wicket door / timber doors Yes / Yes
Max. door width 6000mm
Max. door leaf surface 15.00m²

Operator Details:

Motor 24 V DC gear drive
Mains voltage 230 V - 240 V AC, 50 / 60 Hz
Power input 0.2 kW
Pull and push force 750 N
Peak force 1000 N
Door travel speed ¹ max. 25 cm/s ¹ for travel in the OPEN direction
max. 14 cm/s ¹ for travel in the CLOSE direction
Standby < 1 watt
Housing Stainless steel and plastic, galvanized steel base plate
Temperature range -20°C to +60°C
Protection category Only for dry rooms

Control Electronics:

Display Double 7-segment display
Operation and programming Control element with Open / Close / PRG buttons
Impulse control Yes
Adjustable power limit Yes
Adjustable soft start and soft stop Yes
Adjustable belt relief Yes
Adjustable operator light / partial opening / ventilation position Yes
Adjustable automatic timer 5 - 300 sec.
Adjustable automatic timer partial opening 5 - 240 min.
Adjustable / pre-set operator light 30 - 600 sec. / 60 sec.
High speed opening function Yes

Equipment:

Hand transmitter 868MHz 2 x 4-button hand transmitter HSE 4 BS
Textured surface with chrome caps
Integrated receiver 868MHz Bi-directional 5-channel receiver BS
Integrated Bluetooth® receiver 2.4GHz Yes
LED lighting 30 LED
Connection for photocell / closing edge safety device Yes
Connection of external control elements Yes
Connection for emergency battery Yes
Quick release operated from the inside Yes
Connecting lead with British 13amp 3-PIN plug Yes
Anti-lift kit for break-in resistance Yes
Universal installation bracket for up-and-over doors and sectional doors Yes

Supplied with full instructions in English.

Operator boom FS 10 (at additional cost):

  • Self-supporting steel boom with polyester/polyamide toothed belt
  • Maintenance-free toothed belt
  • Plastic slide carriage and automatic belt tensioner
  • 1-piece, completely pre-assembled

Note: Installation of photocell is required if automatic timer is activated or impulse control without view of the door.

1) Depending on door type, door leaf weight and door size
