Hormann ProMatic Garage Door Opener BiSecur Series 4 Head Only

Hormann ProMatic garage door opener

Hormann ProMatic Garage Door Opener BiSecur Series 4 Head Only

£199.00

Garage door opener specifications:

  • Max garage door width 5000 mm
  • Max garage door height depends on boom selected
  • Max garage door surface 11.25 m²

Included:

  • Two handsets

Available

  • Description
  • Additional Technical Information
  • Downloads

Description

Garage Door Operator – ProMatic BiSecur – NEW Series 4 (Head Only)

The ProMatic garage door operators feature the same proven Hörmann technology as all Hörmann premium operators. This guarantees reliable function – at an attractive price.

Some of the NEW series 4 operator features include:

  • Energy-efficient LED lighting for bright, even garage illumination
  • Low power consumption of less than 1 watt in stand-by mode
  • Up to 40% faster door opening in comparison to ProMatic series 3
  • HCP interface to connect accessories or external SmartHome systems

ProMatic

  • Pull and push force: 600N
  • Peak force: 750N
  • Opening speed: max. 20 cm/s ¹
  • Door width: up to 5000 mm (max. 11.25 m² door surface)

The ProMatic cannot be used on Hörmann LPU 67 sectional garage doors.

1) Depending on door type, door leaf weight and door size

Garage door operator for domestic use - not suitable for commercial use! For dry areas only.

Product Description:

Door cycles (Open / Close) Per day / per hour 25 / 10
Doors with wicket door / timber doors Timber doors with max. 3.5m door width and 9m² door leaf surface
Max. door width 5000mm
Max. door leaf surface 11.25m²

Operator Details:

Motor 24 V DC gear drive
Mains voltage 230 V - 240 V AC, 50 / 60 Hz
Power input 0.2 kW
Pull and push force 600 N
Peak force 750 N
Door travel speed ¹ max. 20 cm/s ¹ for travel in the OPEN direction
max. 14 cm/s ¹ for travel in the CLOSE direction
Standby < 1 watt
Housing Plastic, galvanized steel base plate
Temperature range -20°C to +60°C
Protection category Only for dry rooms

Control Electronics:

Display LED
Operation and programming Control buttons in the operator cover
Impulse control Yes
Adjustable power limit Yes
Adjustable belt relief Yes
Adjustable operator light / partial opening / ventilation position Yes
Adjustable automatic timer 30 - 180 sec.
Pre-set operator light 60 sec.
High speed opening function Yes

Equipment:

Hand transmitter 868MHz 2 x 4-button hand transmitter HSE 4 BS
Textured surface with plastic caps (black)
Integrated receiver 868MHz Bi-directional 5-channel receiver BS
LED lighting 10 LED
Connection for photocell / closing edge safety device Yes
Connection of external control elements Yes
Connection for emergency battery Yes
Quick release operated from the inside Yes
Connecting lead with British 13amp 3-PIN plug Yes
Anti-lift kit for break-in resistance Yes
Universal installation bracket for up-and-over doors and sectional doors Yes

Supplied with full instructions in English.

Operator boom FS 10 (at additional cost):

  • Self-supporting steel boom with polyester/polyamide toothed belt
  • Maintenance-free toothed belt
  • Plastic slide carriage and automatic belt tensioner
  • 1-piece, completely pre-assembled

Note: Installation of photocell is required if automatic timer is activated or impulse control without view of the door.

1) Depending on door type, door leaf weight and door size
